집 > 상품 > 전기 시험 세트 >
20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery

20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery

aluminum foil lid sealing machine

handheld induction bottle foil sealer

plastic jar sealing heat machine

원래 장소:

중국

브랜드 이름:

YUYANG

인증:

CE

모델 번호:

YYSQ-TC-60AB (3상)

저희와 연락
인용문을 요구하세요
20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery
20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery 20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery 20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery
제품 세부 정보
노동력:
340V-430V
최대 입력 전류:
90A
출력 전력:
60KW
변동하는 주파수:
5-20KHz
냉각수의 유량:
0.08-0.16Mpa 12L/분
수온 보호 포인트:
50c
제품 크기:
주요: 808*530*1260MM 변압기: 840*420*740MM
정미중량 :
본체 : 102kg 변압기 : 78kg
출력 전류:
400-4500A
강조하다:

aluminum foil lid sealing machine

,

handheld induction bottle foil sealer

,

plastic jar sealing heat machine

지불 및 배송 조건
최소 주문 수량
1세트
가격
$2000
포장 세부 사항
합판 상자
배달 시간
5-10 근무일
지불 조건
T/T, L/C, 웨스턴 유니온
공급 능력
달 당 200 세트
관련 제품
좋은 가격 High Frequency Electromagnetic Induction Heating Generator for Steel Bar in Metal & Metallurgy Machinery 온라인으로 비디오

High Frequency Electromagnetic Induction Heating Generator for Steel Bar in Metal & Metallurgy Machinery

가장 좋은 가격 을 구하라
좋은 가격 Mini Automatic Plastic Glass Jar Sealing Machine Handheld Aluminum Foil Heat Hot Induction Packaging with Cap Lid 220v 온라인으로 비디오

Mini Automatic Plastic Glass Jar Sealing Machine Handheld Aluminum Foil Heat Hot Induction Packaging with Cap Lid 220v

가장 좋은 가격 을 구하라
좋은 가격 15KW High Frequency Induction Heating Machine New Metal Copper Pipe Wire Welding Manufacturing Plants Construction Motor Engine 온라인으로 비디오

15KW High Frequency Induction Heating Machine New Metal Copper Pipe Wire Welding Manufacturing Plants Construction Motor Engine

가장 좋은 가격 을 구하라
좋은 가격 20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery 온라인으로 비디오

20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery

가장 좋은 가격 을 구하라
저희와 연락
8613825729462
sales03@yuyangtest.com
86-769-26622869
지금 연락하세요
제품 설명
20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine
Handheld Induction Bottle Foil Sealer for Metal Metallurgy Machinery
Product Characteristics
  • Advanced IGBT inverting device with automatic frequency tracking
  • High-frequency heating with rapid operation - consumes only 20-30% of power compared to electronic tube induction heating
  • Secure voltage operation for reliable and safe performance
  • Manual and automatic regulation with comprehensive protection against over voltage, over current, water shortage, phase failure, and overheating
  • No open flame, noise, or pollution - environmentally friendly and fire-safe operation
  • Recommended applications: Brazing, welding, forging, hot cooperation, melting, quenching, and annealing
Advanced Features
This High Frequency Induction Heating Machine incorporates the most advanced electrical components and unique techniques for rapid, localized metal heating. It can penetrate non-metal materials to heat metals until fusion occurs without direct contact, providing safe, economical, and pollution-free technical solutions.
Key Advantages
  • Portable Design: Integrated construction saves over 80% space and 75% weight compared to traditional transformers, offering superior flexibility with monolithic shell design resistant to weak acids and alkalis
  • Complex Metal Heating: Hand-held machine head uses amorphous magnetic core material for wider frequency range, providing superior heating effects for irregular shaped workpieces
  • Efficient Operation: Rapid heating within 8 seconds, ideal for air conditioning and refrigerator industry copper pipe welding, transformer welding, and other complex applications with stable magnetic field output
Technical Parameters
ModelYYSQ-TC-60AB (Three phase)
Work Power340V-430V
Maximum Input Current90A
Output Power60KW
Fluctuating Frequency5-20KHZ
Output Current400-4500A
Cooling Water Flow Rate0.08-0.16Mpa 12L/Min
Water Temperature Protection50°C
Main Unit Dimensions808×530×1260mm
Transformer Dimensions840×420×740mm
Main Unit Net Weight102kg
Transformer Net Weight78kg
Industrial Applications
  • Brazing Materials: Copper and brass brazing, tungsten steel and stainless steel brazing, iron and copper brazing, aluminum and copper brazing
  • Glasses welding, fishing tool welding, hardware appliances welding
  • Carbide saw and saw-tooth welding, carbide blade welding
  • Jewelry and watches welding
  • Electronic Industry: Motor rotor hot-cooperation, electrode silver soldering and tin soldering
  • Metal implants, bulbs fight electrode
  • Band accessory soldering, golf head, pipe welding
  • Communication equipment soldering, copper coaxial cable connector soldering
20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery 0 20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery 1
Company Information & Support
About Our Company
Based in Guangdong, China, established in 2018. We serve global markets including South Asia (20%), Eastern Asia (20%), Domestic Market (15%), Southeast Asia (15%), Eastern Europe (10%), North America (10%), Oceania (5%), and Western Europe (5%). Our team consists of 11-50 dedicated professionals.
Quality Assurance
Pre-production samples provided before mass production. Final inspection conducted before every shipment to ensure product excellence.
Product Range
Fire Testing Equipment, Environmental Test Chambers, Textile Testing Equipment, Toys Testing Equipment, Wire and Cable Test Machines
Why Choose Us
We are a high-tech enterprise specializing in developing and manufacturing Fire Testing Equipment, Building Material Fire Testers, Wire and Cable Fire Testers, Environmental Test Chambers, Textile Testing Equipment, and Toys Testing Equipment.
Services Provided
Delivery Terms: FOB, CFR, CIF, EXW
Payment Currency: USD, EUR, JPY, AUD, HKD, GBP, CNY
Payment Methods: T/T, L/C, D/P D/A, Credit Card, Western Union, Cash
Languages: English, Chinese
