Name: Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YY410
Price: 25,000.00 USD
Availability: InStock

집 > 상품 > 가연성 시험 장비 >

Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment

fire testing machine for building materials

surface burning characteristics testing equipment

flammability testing equipment with warranty

원래 장소:

중국

브랜드 이름:

YUYANG

인증:

모델 번호:

YY410

저희와 연락

인용문을 요구하세요

Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment

제품 세부 정보

합판 지붕 덮개 재료, 크기:

1,300 (w) × 1,000 (d) × 120 (h)

전원 공급 장치:

380V 50Hz 3 상 5 와이어 시스템

터널 용광로를 테스트하십시오:

3. 길이 7.62m, 오픈 엔드 횡단면 0.45m * 0.3m, Firebrick Max 온도 2500 ℃

버너 각도:

45 °

가스 공급원:

> 95% 프로판 가스; (사용자는 스스로 제공해야합니다 ∎ 빗

가스 압력:

10kpa~50kpa

강조하다:

fire testing machine for building materials

surface burning characteristics testing equipment

flammability testing equipment with warranty

지불 및 배송 조건

최소 주문 수량

세트/세트

가격

pending

배달 시간

지불 조건

l/c, t/t

공급 능력

Building Materials Ignitability Flammability Tester for Single Flame Source Test

가장 좋은 가격 을 구하라

Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment

가장 좋은 가격 을 구하라

YY-121 Building Materials Difficult Flammability Test Equipment

가장 좋은 가격 을 구하라

비디오

Class II A2 생물 안전 캐비닛, 깊이 780mm

가장 좋은 가격 을 구하라

저희와 연락

86-769-26622869

지금 연락하세요

제품 설명

Fire Testing Machine for Building Materials

YY410 UL790 Fire Performance Tester for evaluating surface burning characteristics of building materials and photovoltaic cell modules.

Scope of Application

This equipment evaluates roofing materials exposed to simulated exterior building fires, assessing fire resistance at distances of 1.82m, 2.4m and 3.9m to Class AC. Also suitable for testing photovoltaic cell module fire resistance.

Compliance Standards

UL 1730 Smoke Detector Monitors
UL 790 Standard Test Method for Fire Testing of Roof Coverings
IEC 61730-2 Photovoltaic Modules Appendix A Fire Tests
ASTM F 108-04 Standard Test Method for Fire Tests of Roof Coverings
NFPA 256 Fire Tests for Roof Coverings

Performance Parameters

Plywood roof covering material: 1,300(W) × 1,000(D) × 120(H) mm
Non-combustible test plate to block tempering
Adjustable fan plate: 1,440(L) x 940(H) mm
Corrosion-resistant steel main frame: 1,020(L) x 1,000(D) x 1,473(H) mm
Non-combustible panel assembly: 330(W) x 2,130(D) x 584(H) mm
Test panel air flow rate: 19±8 km/h (5.5m/sec) with anemometer
Independent air duct with honeycomb filter screen
Stainless steel air duct: 2,130(W) x 762(H) x 5,200(L) mm
380V, 50HZ three-phase power fan with reverse system (min flow 300m³/min)
Gas burner: 1.12m long, diameter 60.3mm with 12.7mm wide slit
Gas burner capacity: 22,000Btu/min (387kWh) with automatic flow adjustment
Automatic ignition system (minimum 1.8kVp)
Data acquisition system with LabView programming and NI modules
Industrial control computer with 21-inch monitor and test software
Sample ignition device adjustable to 880±10℃
Rotatable metal grid for material support
Advanced temperature and fan wind speed control systems
Comprehensive gas leakage and carbon monoxide safety alarms
Power requirements: 380V 50HZ three-phase, ≥30KW

Equipment Description

The system consists of an adjustable test platform, non-combustible panel assembly, gas burner, supply fan with air channel, isolation plate, and fire panels. Tests must be conducted in a controlled environment (10-32°C) with all openings closed to prevent external interference.

Before testing, mortar should fill gaps between roof covering material and frame to prevent air/flame passage. Airflow must be calibrated using 1m×1.3m plywood at specified inclination (127mm/300mm).
